Antenna Product

AT-0505-DP01

Indoor Antenna, panel, dual-band 2.4/5GHz, 5dBi, 2x2, dual-polarity RP-SMA (for 7372-E)

Application

Mesh/Client Access

3dB Beamwidth H/V

120/60 degrees

Mounting

Wall

Polarization

Vertical & Horizontal

Connector(s)

RP - SMA Male

Operating Temp

-40C to 70C

Antenna Gain

5dBi

Dimensions

200×200×33

IP Rating

4Indoor

Wi-Fi Band

2.4 GHz / 5 GHz

Weight

260g

AT-0303-VP01

Indoor Antenna, elbow-joint, dual-band 2.4/5GHz, 3dBi, vertical polarity, RP-SMA, pair (for 7372-E)

Application

Mesh/Client Access

3dB Beamwidth H/V

Omni

Mounting

Direct attach

Polarization

Vertical

Connector(s)

RP - SMA Male

Operating Temp

-20°C to 70°C

Antenna Gain

3dBi

Dimensions

95.9mm Straight

IP Rating

Indoor

Wi-Fi Band

2.4 GHz / 5 GHz

Weight

10g per antenna

AT-0005-VP

One 2.4GHz omni-directional antenna, vertically polarized, 5dBi

Application

Mesh/Client Access

3dB Beamwidth H/V

Omni/32 degrees

Mounting

Direct attach

Polarization

Vertical

Connector(s)

N-Male Connector (for 7782-E)

Operating Temp

-45°C to 70°C

Antenna Gain

5.5dBi

Dimensions

255mm Height

IP Rating

IP-67

Wi-Fi Band

2.4 GHz

Weight

200g

AT-0006-HP

One 2.4GHz omni-directional antenna, horizontally polarized, 6dBi

Application

Mesh/Client Access

3dB Beamwidth H/V

Omni/25 degrees

Mounting

Direct attach

Polarization

Horizontal

Connector(s)

N-Male Connector (for 7782-E only)

Operating Temp

-30°C to 70°C

Antenna Gain

6dBi

Dimensions

329 mm Height

IP Rating

IP-67

Wi-Fi Band

2.4 GHz

Weight

260g

AT-0636-0536 Bundle

Bundle of two AT-0636-VP and one AT-0536-HP

Application

Mesh/Client Access

3dB Beamwidth H/V

Omni/33 degrees

Mounting

Direct attach

Polarization

Vertical & Horizontal

Connector(s)

Refer to individual antenna specs

Operating Temp

-30°C to 65°C

Antenna Gain

5.5dBi

Dimensions

Refer to individual antenna specs

IP Rating

IP-67

Wi-Fi Band

5 GHz

Weight

Refer to individual antenna specs

AT-0636-VH

Bundle of one AT-0636-VP and one AT-0536-HP

Application

Mesh/Client Access

3dB Beamwidth H/V

Omni/33 degrees

Mounting

Wall

Polarization

Vertical & Horizontal

Connector(s)

Refer to individual antenna specs

Operating Temp

-30°C to 65°C

Antenna Gain

5.5dBi

Dimensions

Refer to individual antenna specs

IP Rating

IP-67

Wi-Fi Band

5 GHz

Weight

Refer to individual antenna specs

AT-0536-HP

5GHz horizontally polarized 5dBi omni-directional antenna

Application

Mesh/Client Access

3dB Beamwidth H/V

Omni/33 degrees

Mounting

Direct attach

Polarization

Horizontal

Connector(s)

One N-Type Male

Operating Temp

-30°C to 70°C

Antenna Gain

5dBi

Dimensions

200mm Height

IP Rating

IP-67

Wi-Fi Band

5 GHz

Weight

180g

AT-0636-VP

5GHz vertically polarized 5.5dBi omni-directional antenna

Application

Mesh/Client Access

3dB Beamwidth H/V

Omni/33 degrees

Mounting

Direct attach

Polarization

Vertical & Horizontal

Connector(s)

Refer to individual antenna specs

Operating Temp

-30°C to 65°C

Antenna Gain

5.5dBi

Dimensions

Refer to individual antenna specs

IP Rating

IP-67

Wi-Fi Band

5 GHz

Weight

Refer to individual antenna specs

AT-1212-DP

5GHz dual polarized 12dBi 120 degrees sector antenna

Application

PtMP Root/Mesh/Client Access

3dB Beamwidth H/V

120/15 degrees

Mounting

Wall/Pole Mount, mounting kit included

Polarization

Vertical & Horizontal

Connector(s)

Two N-Type, two 1m RF cables included

Operating Temp

-55°C to 65°C

Antenna Gain

12.5dBi

Dimensions

200×200×33mm

IP Rating

IP-67

Wi-Fi Band

5 GHz

Weight

1000g

AT-2101-DP

5GHz dual polarized high gain 21dBi directional antenna

Application

Long range backhaul /PtP/PtMP Non-Root

3dB Beamwidth H/V

10/10 degrees

Mounting

Wall/Pole Mount, mounting kit included

Polarization

Vertical & Horizontal

Connector(s)

Two N-Type, two 1m RF cables included

Operating Temp

-55°C to 65°C

Antenna Gain

21dBi

Dimensions

305×305×15mm

IP Rating

IP-67

Wi-Fi Band

5 GHz

Weight

900g

AT-2401-DP

5GHz dual polarized high gain 24dBi directional antenna

Application

Long range backhaul /PtP/PtMP Non-Root

3dB Beamwidth H/V

7-9/7-9 degrees

Mounting

Wall/Pole Mount, mounting kit included

Polarization

Vertical & Horizontal

Connector(s)

Two N-Type, two 1m RF cables included

Operating Temp

-40°C to 65°C

Antenna Gain

V24.5dBi / H23.5dBi

Dimensions

370×370×40mm

IP Rating

IP-67

Wi-Fi Band

5 GHz

Weight

1800g
